Specifications
Description
Environments
Specifications
  • Maximum Output: 1350kW Gas or Oil
  • Boiler: Viessmann
  • Burner: Oil: Riello RL130 Gas: Riello RS130
  • Pumps: Grundfos TPD 80/150 Twin Head
  • Temperature Range: Flow: 80 (90max) Return 70 (60min)
  • LTHW Connections: DN100 (DN125 Possible)
  • Electrical: 32 amp phase 3
  • Water Connection: 15mm
  • Flow Rate: 16.6 kg/s and 120kPA (both pumps can run at 33.2kg/s)
  • Dimensions (LxWxH): 6058mm x 2438mm x 2591mm
  • Weight: 6 tonne (approx)
  • Pressurisation Plant: Included (800L expansion)
  • Telemetry: Trend IQ4 controller with GSM modem reporting.
  • Variable Temperature: Yes
  • Noise: 75dBA
  • Handling Options: HIAB
  • HWS Connection: DN40
  • HWS Flow Rate: 1 Kg/s
  • Max HWS Temperature: 60˚C
  • Maximum Static: 6 BAR
  • CWS Connection: DN40
