750kW Gas/Oil Fired Packaged Boiler Plant

24HR HELP
FREE ESTIMATE
01622 632 918

In Stock

Unbeatable service and reliability

  • Site Delivery & Installation
  • 92% Fuel Efficiency Rating
  • Packaged plant room - full BMS control
  • Bespoke Plant Construction Available
    • 3030mm x 2438mm x 2599mm

    • 3.5 tonnes (approx.)

  • Get FREE estimate
  • PDF Download
  • Free Site Survey
  • OFTEC Engineers
  • Full BMS Control

Need Help? 01622 632 918

Specifications
Description
Environments
Specifications
  • Maximum Output: 750kW Gas or Oil
  • Boiler: Viessmann
  • Burner: Oil
  • Oil: Riello RL100
  • Gas: RS100
  • Pumps: tpd 100-130/4 (twin head) fixed speed
  • Temperature Range: 60-90°C
  • LTHW Connections: DN100
  • Electrical: 32 amp 3 phase
  • Gas Connection: 50mm
  • Water Connection: 15mm
  • Flow Rate: 19.61kg/s and 117kPA
  • Dimensions (LxWxH): 3030mm x 2438mm x 2599mm
  • Weight: 3.5 tonnes (approx.)
  • Pressurisation Plant: Included (500l expansion)
  • Telemetry: Trend IQ3 controller with GSM modem reporting
  • Variable Temperature: Yes
  • Noise: 75 dBA
  • Handling Options: HIAB
  • HWS Connection: DN40
  • HWS Flow Rate: 1 Kg/s
  • Max HWS Temperature: 60°C
  • Maximum Static: 6 BAR
  • CWS Connection: DN40
Specification PDF Download
